Model		AD30T
Clamping force	kN(tf)	290(30)
Space between tie bar	mm*mm	310*290
Plate dimension	mm*mm	440*420
Opening Stroke	mm	230
Mold thickness	mm	150～300
Positioning ring	mm	60
Ejection force	kN(tf)	9(1)
Ejection Stroke	mm	50
Injection system
Screw diameter	mm	18	20	22	20	22	25
Shot weight(GPPS)	oz	0.63	0.77	0.95	0.91	1.12	1.44
Shot weight(GPPS)	g	18	22	27	26	32	41
Rubber melting speed	r/min	400			400
Injection distance	mm	73			87
Nozzle Protruding	mm	30			30
Nozzle contact force	kN	11			11
Injection unit		S67L			S85L
Injection speed	mm/s	600			600
Injection rate	cm³/s	153	188	228	188	228	294
Injection pressure	MPa	280	224	179	280	224	179
Holding pressure	MPa	224	179	143	224	179	143
Plasticization capacity	kg/h	10	13	18	13	18	26
Injection unit		S67M			S85M
Injection speed	mm/s	300			300
Injection rate	cm³/s	76	94	114	94	114	147
Injection pressure	MPa	280	224	179	280	224	179
Holding pressure	MPa	224	179	143	224	179	143
Plasticization capacity	kg/h	10	13	18	13	18	26
Other
Machine Dimension	mmmmmm	32009001680			32009001680
Machine weight	T	1.9			2

Direct Drive Mechanism For Injection

Highly responsive and high speed injection control is achieved with direct-drive structure mechanism as the core of the injection

High response ,low inertia servo motor with corresponding low inertia load design to achieve the aim of the actual closed cycle and high acceleration.

Applied rotation mechanism for the injection unit,which is more convenient for disassembling screw components and effectively reduce the operation time.

Equipped with high-precision encoder and injection pressure sensor,which could control screw position with accuracy and stabilize rubber melting,injection .pressure holding and back pressure operation.

Content-rich standard configuration


Heat cover Adopt double-deck heat cover of stainless steel.Reduce energy consumption of heating system. Avoid operator be scalded due to mishandling.	Injection safety protector Reasonable design which avoids operator being scalded due to mishandling and facilitates operation,greatly improves work efficiency.	Material clean-up plate Configured stainless steel cleaning plate under the nozzle to facilitate waste removal,avoiding waste being left on the gap of machine while clean-up operation Jess troubled during maintenance.


Chute type erecting bed for hopper Humanized design .easily installed; Adopts high-quality steel.stronger and make it more durable ,safely and reliably to use.	Color touch display 15 inch HD color touch display , its clear image makes it handy to operate, rotatable design which is more convenient for technical operation.	Three-color alarm light When emergency occurs,the device will remind you what kind of situation by different colors ,you can cope with urgent situations more easily,greatly increase the production management efficiency.

Injection speed controlled

Applied low inertia load design which could strengthen basic characteristics of injection speed responsiveness and low speed injection traceability.

Optimized plate design

Stress concentration plate design unifies clamping force of the mold bears.improving the issues of inadequate venting and nonuniform of pressure on mold surface.what occurs on traditional toggle machines,significantly increasing the mold service life.


Direct-drive closing mold Direct drive mechanism,quick response for opening and closing mold.excellent protection for low pressure.	High standard clamping unit High standard clamping force and parallelism adjustment are achieved with stable clamping state and reduced mold losses.	Support plate High wear resistance and low friction of the movable plate supports sliding block, extends mold service life.	Full-automatic lubricating device Reduce co&t of maintenance。


Fixed plate structure Optimized fixed plate structure. reduces the tilting deforming of plate	Stress concentration moving plate Optimized moving plate structure, significantly improving the precision of locking face.	Machinery safety bar Reliable machinery safety bar.	Frame High strength frame design and adopt thick wall structurs stesl components, reducing the vibration of fast opening and closing.

In Response To Diversified Plastics

With requirement of higher heat resistance for high-precision molded parts and the advent of plastics products that can substitute metal parts.the performance requirements of the molded products are increaing.Depending on the characteristics of the resins,from PO with long molding cycle to PC for optical lenses and ABS for structural parts.spdcially designed and developed screws by Anslrength based on factors such as resin heating temperature and injection speed may be used.together with specialized screw components with special material.special processing and special treatment.

Screw Options Of Various Types

Diversified Products

AD 30T Technical Parameters
